SKYRC PDC100 GaN CHARGER (USB-C - 100 W) SK-200028

SKYRC PDC100 GaN CHARGER (USB-C - 100 W) SK-200028

With advanced GaN (Gallium Nitride) power components and SkyRC’s proprietary charging and thermal technologies, PDC100 delivers high efficiency and cooler performance—all in a compact form. Lightweight yet powerful. Effortless charging!

Combining fast-charging technology with 100W of output, PDC100 delivers powerful, efficient performance that keeps everything running—without the wait.

Designed to power SkyRC chargers with precision—and just as capable with your phone, tablet, laptop, or Switch. Whether you’re racing RC, working, or gaming, PDC100 is your go-to power companion. One device. All charged.



Key Features :
• Wide AC input range: 100-240V AC, 50/60 Hz
• High-efficiency GaN technology
• 100W output with integrated USB-C extension cable (30 cm)
• Supports PD3.0, PPS, and QC2.0/3.0 protocols
• Intelligent line loss compensation
• Multiple protection mechanisms (OCP, SCP, OVP, UVP, OTP)
• Compact design with high power density.

Technical Specifications :
● Supply Voltage/Frequency: 100-240V AC, 50/60 Hz
● Input Interface: AC Main Connector
● Output Interface: Integrated 30cm USB-C Output Cable
● Rated Output Power: 100W
● Standby Power: < 0.3W
● Supported Protocols: PD3.0, PPS, QC2.0/3.0
● USB-C PD3.0 Output: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A
● USB-C QC2.0 Output: 5V/3A, 9V/12V (Max 20W)
● USB-C QC3.0 Output: 5V-12V (Max 20W)
● USB-C PPS Output: 5V-21V
● Voltage Range Output (no load) 5V 4.9V - 5.2V
● Output voltage range (no load) 9V 8.9V - 9.3V
● Output voltage range (no load) 12V 11.7V-12.3V
● Output voltage range (no load) 15V 14.6V-15.4V
● Output voltage range (no load) 20V 19.5V-20.5V
● Load compensation +80 mV/A (Max) For example, under a 5A load, 20V output = 19.5V-20.9V
● Conversion Efficiency > 86%
● Overcurrent Protection: 3A 3.6±0.3A / 5A 5.6±0.3A
● Short Circuit Protection: Yes
● Dielectric Strength: AC-USB-C 3000V, leakage < 10mA, 60s
● Operating Environment: 0°C to 40°C
● Humidity: 5% ~ 75% RH (non-condensing)
● Storage Environment: -10°C to 70°C
● Humidity 5% to 75% RH (non-condensing)
● Dimensions (L x W x H) 63.5 x 62 x 32 mm
● Weight Approx. 150 g

Product Contents :
● 1 x PDC100 GaN Charger
● 1 x Power Cord
● 1 x User Manual
